Type
Panel Saw
SKU
8300642
Part Number
SEGA350-240V
Brand
Sicar
Size
350mm (14") 3.2m
Status
Available
Description
Specifications:
- Main Blade Diameter: 250-350 x 30mm
- Main Blade Speed: 4000 RPM
- Scoring Blade Diameter: 120 x 22mm
- Scoring Blade Speed: 8000mm
- Max Depth of Cut @ 45 °: 92mm (350mm Blade)
- Max Depth of Cut @ 90 °: 120mm (350mm Blade)
- Max Rip Capacity: 1250mm
- Main Table Size: 910x550mm
- Main extend Table Size: 910x760mm
- Side extend Table Size: 500x550mm
- Dust Extraction Outlet: 120mm
- Main Blade Motor Output: 3KW 4HP
- Scoring Blade Motor Output: 0.5KW 0.75HP
- Net/Gross Weight: 610/710KG
- Main Package: 2220 x 1030 x 1150mm
- Sliding Table Packing Size: 3560 x 420 x 210mm
- CE Style Overhead Guard Included
Additional Information
Model
Technical - Main
Power Source
Power Source
Any source of power which provides the energy required to drive a piece of machinery or equipment and includes, but is not limited to: electrical, steam, hydraulic, water, air, mechanical, radiation, and thermal forms of energy.
240V 50Hz Single Phase
Blade - Electric Rise / Fall
No
Cut Max. Depth @ 45°
92mm
Cut Max. Depth @ 90°
120mm
Rip Capacity
1250mm
Technical - Saw
Sliding Table (Cross Cut) Size
3200x375mm
Blade (Main) - Bore Size (mm)
30mm
Blade (Main) - Diameter (Max.)
350 mm
Blade (Main) - Speed
4000RPM
Blade (Scoring) - Diameter (Max.)
120 mm
Blade (Scoring) - Speed
8000RPM
Blade Tilt
0-45°
Dimensions
Product Weight (Net Weight)
610 kg
Country of Origin
Manufactured in
China
Safety
Dust Port
Main Saw: 100mm / Overhead Guard: 75mm or 100mm
Workshop (Site) Info
Electrical Connection
Excludes Plug & Lead (must be connected by Licensed Electrician)
Packaging + Shipping
Shipping Weight (Gross)
770.0 kg
Shipping Notes
This product exceeds hand unloading limits and requires a tail lift truck or forklift at the unloading location (Receivers end).
